Metrix
Current-fed linear projectors made of aluminium extrusion with remote driver, available in four lengths and three wattages.
The new Microflat optical systems guarantee high efficiency, very high beam precision in contained shapes and very low glare factors.
Dedicated to professional design, they are available in two symmetrical beam angles, an asymmetrical grazing washer and a specific transverse wide beam in three power ranges with outputs of 1300Lm/m, 2600Lm/m and 3800Lm/m.
The complete range of accessories allows for ceiling, cornice, shelf and adjustable installations.
Specifications
| Power supply |  CC
|
| CCT |  2700K
 3000K
 3500K
 4000K
|
| Certification |  CE Compliance
|
| Isolation class |  Class III
|
| Class F |  YES
|
| CRI |  92
 98
|
| Incandescent wire |  650°
|
| Warranty |  5 years
|
| Protection class |  IP40
|
| Wall Washer Lighting |  Grazing Washer
|
| Cove Lighting |  Cove Light Asymmetrical
 Cove Light Symmetrical
|
| Lifetime |  L80B10 150.000 h
|
| Operating temperature |  -10° / +35°
|
Features and Advantages
360mm / 720mm / 1080mm / 1440mm
CRI: 92/98
CCT: 2700K/3000K/3500K/4000K
1300lm/mt / 2600lm/mt / 3800lm/mt
ON-OFF/1-10V/DALI/PUSH/PHASE CUT/CASAMBI
4 Optics
1 Wall Washer
3 Finishes
