Wolf Projector Base

Base projector with LED light source, die-cast aluminium body and glass sealed optical chamber.
The optical body allows a rotation of 305° and a tilt of 135°. Power ratings of 7W and 13W available in 2700K, 3000K or 4000K in CRI95 or 3000K in CRI85. Luminous flux maintenance of 115,000 hours according to L80 B10.
Natural powder-coated finish options include carbon grey, mud brown, sand, matt white txt and rust effect.
The choice of optics includes Spot, Flood, Medium and Wide.
WOLF is available with a range of optical accessories including honeycomb grid (factory fitted) as well as coloured ring or visor snoot and adjustable elliptical lens (18°x40° for 7W or 23°x65° for 13W) (to be ordered separately).
The coloured rings are made of UV-resistant PMMA and are available in translucent orange, translucent blue, translucent green and neutral. IP66 degree of protection.
Class I luminaire including ON/OFF ballast installed in the base. This product complies with EN 62471:2008 and subsequent amendments/updates on photobiological risk of electrical lighting systems and is classified as low risk (RG1).

Specifications

CCT	2700K 3000K 4000K
Certification	CE Compliance
Isolation class	Class I - Earth contact
Class F	YES
CRI	85 95
Incandescent wire	850°
Warranty	5 years
Protection class	IP66 IK08
Shaded accent lighting	Spot Flood Medium Wide
Lifetime	L80B10 115.000 h
Operating temperature	-10° / +30°
